Accessories Egida and Eldorado


Servos for ailerons and flaps:

(Required 4 pcs. for model)

Futaba S3150

  •  Torque (4.8V): 3.7kg・cm
  • Speed (4.8V): 0.24sec/60°
  • Dimensions: 30×11×29mm
  • Weight: 23g
  • Operating voltage: 4.8V-6.0V
  • Shaft diameter: 6mm
  • Metal gear
  • With ball bearings
  • Price see our price list Egida or price list Eldorado.

Futaba S3172SV

  • Torque (6.0/7.4V):  3.3/4.1kg・cm
  • Speed (6.0/7.4V): 0.29/0.23sec/60°
  • Dimensions: 30×11×29mm
  • Weight: 20g
  • Kabellänge: 130mm
  • Operating voltage:   5.0V-8.4V
  • Shaft diameter:  6mm
  • Metal gear
  • With ball bearings

Servos for V-tail:

(Required 4 pcs. for model)

Futaba S3777SV

  • Torque (6.0/7.4V):  2.2/2.6kg・cm
  • Speed (6.0/7.4V): 0.12/0.14sec/60°
  • Dimensions: 21.8×11×21.9mm
  • Weight: 10g
  • Operating voltage:   6.0V-8.4V
  • Shaft diameter:  5mm
  • Metal gear
  • With ball bearings

KST DS315MG

  • Torque (6.0/8.4V):  3.5/4.5kg・cm
  • Speed (6.0/8.4V): 0.09/0.07sec/60°
  • Dimensions: 23×12×27.5mm
  • Weight: 20g
  • Operating voltage:   4.8V-8.4V
  • Shaft diameter:  5mm
  • Metal gear
  • With ball bearings
  • Price see our price list Egida or price list Eldorado.

Drive unit:

Motor AXI 2217/16 CYCLONE + prop  Graupner 13×7″

(for batery Lipol 3S)

Outrunner with a protective jacket.
kV : 1050/V
Motor diameter: 32.8mm
Motor lenght: 63mm (without shaft)
Prop cone: Alu, diameter 38mm
Prop: Graupner CAM Folding Prop 13×7″
Total weight of the drive unit: 145g
Current: 33A
Climb rate of the model: ca. 7m/s
Recommended batery: Li-Pol 3S/1800-2000mAh

Price see our price list Egida or price list Eldorado.



Motor AXI 2217/20 CYCLONE + prop  Graupner 12×6″

(for batery Lipol 4S)

Outrunner with a protective jacket.
kV : 840/V
Motor diameter: 32.8mm
Motor lenght: 63mm (without shaft)
Prop cone: Alu, diameter 38mm
Prop: Graupner CAM Folding Prop 12×6″
Total weight of the drive unit: 145g
Current: 26A
Climb rate of the model: ca. 8m/s
Recommended batery: Li-Pol 4S/1200-1600mAh

Price see our price list Egida or price list Eldorado.

ESC YGE 35 LVT with telemetry

Cell number: 2-6 LiPo.
Adjustable HV-BEC from 5,5 to 8,4V .
High BEC-current rating: 5A permanent  / 10A peak.
Dimensions: 34 x 23 x 8 mm
Weight with / without cables: 13g / 25g
Telemetry: Graupner HoTT V4, Jeti ExBUS, Multiplex Sensor BUS V2, YGE-protocol for different telemetry-connections for example via S32 (new Jlog).

Price see our price list Egida or price list Eldorado.
